Bussmann原装正品 S501 双铜帽带引线 陶瓷保险丝
参数表
| 料号 | 额定电压 | 分断能力 | 冷电阻 | 熔断能量值 |
| S501-50-R | 250 | 1500 | 157.5 | 0.0017 |
| S501-63-R | 250 | 1500 | 39.0 | 0.0005 |
| S501-80-R | 250 | 1500 | 27.9 | 0.0011 |
| S501-100-R | 250 | 1500 | 20.0 | 0.0018 |
| S501-125-R | 250 | 1500 | 12.3 | 0.0037 |
| S501-160-R | 250 | 1500 | 8.5 | 0.008 |
| S501-200-R | 250 | 1500 | 6.0 | 0.02 |
| S501-250-R | 250 | 1500 | 4.4 | 0.027 |
| S501-315-R | 250 | 1500 | 3.3 | 0.01 |
| S501-400-R | 250 | 1500 | 2.2 | 0.018 |
| S501-500-R | 250 | 1500 | 0.460 | 0.038 |
| S501-630-R | 250 | 1500 | 0.340 | 0.064 |
| S501-800-R | 250 | 1500 | 0.245 | 0.097 |
| S501-1-R | 250 | 1500 | 0.231 | 0.146** |
| S501-1.25-R | 250 | 1500 | 0.176 | 0.313** |
| S501-1.6-R | 250 | 1500 | 0.113 | 0.748** |
| S501-2-R | 250 | 1500 | 0.073 | 2.0 |
| S501-2.5-R | 250 | 1500 | 0.053 | 3.9 |
| S501-3.15-R | 250 | 1500 | 0.037 | 8.1 |
| S501-4-R | 250 | 1500 | 0.027 | 14 |
| S501-5-R | 250 | 1500 | 0.019 | 25 |
| S501-6.3-R | 250 | 1500 | 0.014 | 48 |
| S501-8-R | 250 | 1500 | 0.009 | N/A |
| S501-10-R | 250 | 1500 | 0.008 | N/A |
